The Honeywell MC-TPIX12 (51304084-175) is a high-performance Pulse Input Module designed for use within the Honeywell FSC (Fail Safe Control) safety system environment. This module is engineered to process pulse-based signals, providing reliable data acquisition for critical industrial processes. It features conformal coating to enhance durability in harsh operating environments and maintains compliance with CE standards.
Features
8-channel pulse input capacity for high-density signal monitoring.
Conformally coated circuitry for improved resistance to environmental contaminants.
Designed for integration with IOP MU-PPIX02 or MC-PPIX02 modules.
High-precision frequency measurement with a rate accuracy of ±0.01%.
Robust input protection supporting up to ±30V without damage.
Standardized 500 ms PV update rate across all 8 channels.
Technical Specifications
Model Number
MC-TPIX12 (51304084-175)
Input Points
8
Input Impedance
10 kOhm minimum
PV Update Rate
500 ms (for 8 channels)
Rate Accuracy
±0.01% of input frequency
Rate Resolution
±0.4 Hz
Input Range (No Damage)
±30 V maximum
Manufacturer
Honeywell
Installation Guidelines
Ensure the system power is completely disconnected before inserting or removing the module from the rack.
Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to internal sensitive components.
Verify that the module is securely seated in the designated slot to ensure proper backplane connectivity.
Route signal cabling away from high-voltage lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
Confirm that the module is compatible with the existing IOP hardware (MU-PPIX02 or MC-PPIX02) prior to commissioning.
FAQ
Does this module support redundancy?
No, the MC-TPIX12 pulse input module does not support redundant configurations.
What is the primary function of the MC-TPIX12?
This module is specifically designed to interface pulse input signals into the Honeywell FSC safety system, providing accurate frequency and rate monitoring for process automation.
