The Honeywell 51304584-200, also cataloged as the 51304584-200 I/O Control Board, operates as a dedicated hardware component for peripheral signal conditioning and multi-connector interface routing within EPDG and EPDG2 peripheral interface configurations. The panel-mounted card manages localized signal translation matrices natively at the hardware tier to maintain real-time tracking between auxiliary hardware devices and core system controllers.
Hardware Specifications
Parameter
Specification
Model
51304584-200
Brand
Honeywell
Series
EPDG / EPDG2 Subsystem Series
Origin
United States
Weight
0.40 lbs (0.18 kg) net component mass
Dimensions
Standard multi-connector panel mount profile geometry
Mounting Profile
Dedicated panel mount structural configuration
Interface Ports
High-density multi-connector array
Core Application
EPDG and EPDG2 Peripheral Interface Routing
Power Consumption
Regulated logic supply via inter-board connector paths
Product Type
Distributed I/O Boards
Process Control & DCS Instrumentation Interface
Channel-to-Channel Isolation and Peripheral Gating The control card utilizes dedicated boundary tracks to provide electrical separation across its multi-connector interface. This internal layout ensures that external data transitions or inductive surges from adjacent peripheral blocks cannot compromise core logic lines, maintaining channel-to-channel isolation parameters across all linked data points.
4-20 mA HART Loop Protocol and Field Routing Isolation The board assembly handles auxiliary peripheral data mapping while remaining electrically isolated from upper-tier 4-20 mA HART loop protocol field wiring drops. This structural zoning ensures that mechanical connections or peripheral card changes do not feed noise back into active analog control signals or interrupt the main DCS processing cycle.
