GE IS200ACLEH1BAA Control Layer Module is a key component of the EX2100 excitation control system, designed to manage control logic, communication, and interface functions within turbine generator applications. It provides the essential control layer for coordinating exciter operations and ensuring reliable system performance.
Specifications:
Manufacturer: General Electric (GE)
Part Number: IS200ACLEH1BAA
Product Type: Control Layer Module
Series: EX2100
Country of Manufacture: USA
Technology: Surface‑mount design
Operating Temperature: –30°C to +65°C
Dimensions: Standard GE module form factor
Availability: In Stock
Functional Description:
Control Layer Role: Provides the central control logic for exciter operations in the EX2100 system.
System Integration: Interfaces with DSPX, EISB, and feedback boards to coordinate excitation control.
Communication Functions: Supports fiber‑optic and backplane communication for noise‑immune data transfer.
Reliability: Designed for continuous operation in demanding turbine environments.
Features:
Centralized Control: Manages exciter logic and communication across subsystems.
High Reliability: Built for industrial turbine excitation systems.
Seamless Integration: Compatible with other EX2100 modules (DSPX, EISB, EDCF).
Robust Construction: Engineered for long‑term durability in harsh operating conditions.
Diagnostic Support: Provides interface points for monitoring and troubleshooting.
