The GE Fanuc IS200VCMIH1BCD VME Bus Master Control Board is a critical module in Mark VI turbine control systems. It functions as the master controller for the VME bus, coordinating communication between processors and subsystems to ensure synchronized and reliable turbine operation.
Specifications
Manufacturer: GE Fanuc
Model Number: IS200VCMIH1BCD
Type: VME Bus Master Control Board
Application: Mark VI turbine control systems
Bus Type: VME backplane communication
Nominal Voltage: 24 VDC logic supply
Processor Role: Master controller for bus arbitration and communication
Form Factor: Single‑slot PCB board
Operating Temperature: −20 °C to +70 °C
Dimensions: Standard GE VME module size
Weight: ~1.2 kg
Features
Master Control Function: Provides bus arbitration and synchronization for VME subsystems
Reliable Communication: Ensures stable data transfer across turbine control modules
Industrial Durability: Built for continuous operation in demanding environments
System Integration: Fully compatible with GE Mark VI architectures
Multi‑Layer PCB Design: Optimized for high‑speed signal routing
Maintenance Friendly: Modular design allows easy replacement and servicing
