  • GE Fanuc IC693CPU364-CJ CPU Processor

أُوكَازيُون

أُوكَازيُون

GE Fanuc IC693CPU364-CJ CPU Processor

في الأوراق المالية!
  • Part Number: IC693CPU364-CJ
  • Brand: General Electric
  • Type: CPU Processors
  • Dimensions: 4x18.5x12.7cm
  • Country of Origin: USA
  • Barcode: 8537101190

Additional Specifications

Color / Pattern
  • Black
  • Gray
Power Source
  • DC-powered
Communication Protocols
  • Ethernet
Controller Design
  • Modular
Tags: CPU Processors , GE Fanuc Series 90-30

وصف المنتج

Configured for central processing and baseplate management in Series 90-30 PLC architectures, the GE Fanuc IC693CPU364-CJ (IC693CPU364-CJ CPU Processor) provides direct physical/electrical execution.

Suffix Breakdown & Model Matrix

Suffix / Identifier Technical Description / Hardware State
IC693 Base platform designation indicating Series 90-30 PLC hardware infrastructure.
CPU364 Core processor functional identifier denoting 80386EX architecture with integrated Ethernet communications.
-CJ Hardware revision and regional manufacturing suffix indicating specific firmware iteration and component build state.

Hardware Specifications

Parameter Specification
Model IC693CPU364-CJ
Brand GE Fanuc
Origin USA
Weight 0.45 kg
Dimensions Standard Series 90-30 single-slot module format
Operating Temp 0 deg C to 60 deg C
Power Consumption 1.51 A at +5 VDC
Processor Type 80386EX, 25 MHz
Scan Rate 0.22 ms per 1K logic / Boolean contacts
Baseplate Support 1 CPU baseplate, up to 7 expansion/remote baseplates

Backplane Bus Communication Velocity and Firmware Compatibility

The module communicates via high-speed backplane bus communication velocity across the Series 90-30 rack system to coordinate I/O data exchange. Firmware flash compatibility is supported through onboard memory blocks, allowing synchronization with programming software revisions and Ethernet communication stacks. Backplane bus communication velocity operates within deterministic limits to manage up to seven expansion or remote baseplates without data collision. I/O density scaling enables expansive remote node integration while maintaining fast scan rates and reliable register updates.

Frequently Asked Questions

Q: What are the electrical load requirements of the IC693CPU364-CJ module on the baseplate power supply?

A: The CPU draws 1.51 A at +5 VDC from the backplane power supply bus.

Q: Does the unit support hot-swapping within an active Series 90-30 rack?

A: Hot-swapping is restricted; main rack power must be completely de-energized before inserting or extracting the CPU module to prevent backplane bus damage or data corruption.

Q: What are the specifications of the onboard Ethernet protection fuse?

A: The Ethernet circuit utilizes a replaceable fuse rated at 125 V, 1 A with physical dimensions of 2.69 x 2.69 x 6.1 mm.

Field Installation Guidelines

  1. Ensure the PLC baseplate power supply is fully de-energized and locked out prior to handling or installing the module.
  2. Inspect the CPU slot for mechanical debris and align the module edge connectors with the backplane guides.
  3. Push the module firmly into the slot until the backplane connector is fully seated and secure the top/bottom retaining latches.
  4. Connect the Ethernet communication cable to the onboard RJ45 port, ensuring network wiring adheres to standard industrial shielding practices.
  5. Apply system power and observe the LED status indicators to verify successful power-up diagnostics and CPU operational mode.
