The Honeywell 10106/2/1, also cataloged as the 10106/2/1 Digital Input Module, provides discrete input signal acquisition for Honeywell control systems, designed with a compact metal housing for rack integration.
Hardware Specifications
Parameter
Specification
Model
10106/2/1
Brand
Honeywell
Origin
Not specified
Weight
1.5 kg
Dimensions
2.5 cm x 14 cm x 19.1 cm
Operating Temp
Not specified
Power Consumption
Not specified
Product Type
Digital Input Module
Color
Metal color
4-20 mA HART Loop Protocol
Although primarily a digital input module, the 10106/2/1 integrates into Honeywell distributed control architectures where analog and digital modules coexist. Channel-to-channel isolation is maintained across connected modules, ensuring stable signal integrity. Cold junction compensation (CJC) is supported indirectly through compatible input boards powered by Honeywell supply units, enabling accurate thermocouple measurements in mixed I/O environments.
Frequently Asked Questions (FAQ)
Q: What type of housing does the 10106/2/1 use? A: It is built with a metal-colored enclosure for durability and mechanical stability.
Q: Can the module be hot-swapped? A: No. Modules must be powered down before removal or insertion to prevent disruption of input signals.
Q: What is the shipping weight of the module? A: The module ships at approximately 1.5 kg.
Field Installation Guidelines
Ensure proper rack mounting with full mechanical engagement.
Maintain separation between digital input wiring and high-voltage circuits.
Verify grounding of shields to minimize electrical noise.
Confirm dimensional clearance (2.5 x 14 x 19.1 cm) before installation.
Observe handling precautions to avoid mechanical stress on connectors.
