The Yokogawa NFSB100-S50 Bus Repeat Module is designed for CENTUM control systems, providing reliable ESB bus signal extension and repeat functionality. It ensures stable communication across extended distances and multiple I/O nodes in distributed automation environments.
Specifications
Manufacturer: Yokogawa
Part Number: NFSB100-S50
Type: Bus Repeat Module
System Compatibility: CENTUM series control systems
Function: ESB bus signal repeat/extension
Transmission Speed: 128 Mbps (I/O data transfer)
Transmission Distance: Extends bus communication beyond standard 10 m
Connectable Nodes: Supports multiple I/O modules
Current Consumption: ~0.5 A
Operating Temperature: −20 °C to +70 °C
Weight: ~0.3 kg
Warranty: 12 months
Features
Signal Extension: Extends ESB bus communication distance for large installations
Stable Transmission: Maintains 128 Mbps high‑speed data transfer
Reliable Integration: Ensures seamless communication between distributed I/O modules
Compact Design: Lightweight module for easy rack installation
Industrial Durability: Built for continuous operation in automation environments
Easy Configuration: Standardized interface simplifies setup and replacement
