Yokogawa ATD5S-00 Pressure Clamp Terminal Block

The Yokogawa ATD5S-00, also cataloged as the ATD5S Terminal Block, operates as a dedicated hardware component for digital output signal termination within Yokogawa CENTUM VP control systems.

Hardware Specifications

DCS Signal Integrity & Process Control Architecture

• 4-20 mA HART Loop & Digital Switching Isolation: Facilitates direct physical wiring interfaces for 32 digital output channels, preventing cross-channel electrical noise propagation to CENTUM VP FIO cards.
• Integrated Field Surge Suppression: Features built-in surge absorbers to suppress high-voltage field transients and fulfill EN 61000-6-2 surge immunity limits.
• Channel-to-Channel Environmental Protection: Incorporates ISA Standard G3 class conformal treatment options to protect internal terminal connection points from corrosive gaseous contaminants.

Frequently Asked Questions

Q: Can the ATD5S-00 terminal block be removed from the FIO module while field wiring remains physically clamped?

A: Yes, the terminal assembly unlatches directly from the front face of the FIO card without necessitating wire insertion release or rewiring operations.

Q: Does the integrated surge absorber require external earth grounding connections?

A: Yes, transient voltage suppression relies on low-impedance ground bonding through the FIO mounting baseplate or rail assembly to route surge current to functional earth.

Field Installation Guidelines
