- Yokogawa ADV159-P00 Digital I/O Modules
Sale
Yokogawa ADV159-P00 Digital I/O Modules
No reviews
In stock!
- Part Number: ADV159-P00
- Brand: Yokogawa
- Type: Digital I/O Modules
- Dimensions: 3.3x10.7x13cm
- Country of Origin: Japan
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
| Communication Protocols |
|
| Controller Design |
|
Product Description
The Yokogawa ADV159-P00 serves as the primary ADV159 Digital I/O Modules utilized to execute 32-channel input and transistor contact output tasks across distributed control network platforms.
Suffix Breakdown & Model Matrix
| Model / Suffix Code Element | Designation & Specification Details |
|---|---|
| ADV159 | Digital I/O Module (32-channel input, transistor contact output, isolated) |
| -P | Pushbutton input function supported |
| 0 | Standard configuration build |
| 0 | Basic type standard version |
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | ADV159-P00 |
| Brand | Yokogawa |
| Origin | Japan / Authorized Manufacturing Facility |
| Weight | Approximately 0.40 kg |
| Dimensions | Standard Yokogawa Modular Rack Form Factor |
| Operating Temp | Standard industrial rack rating |
| Power Consumption | 330 mA (5 V DC) maximum current consumption |
| Number of I/O Channels | 32-channel input |
| Signal Isolation | Isolated channels |
| Contact Input OFF Signal | 100 kΩ or more |
| Contact Input ON Signal | 200 Ω or less |
| Voltage Input OFF Signal | 4.5 to 25 V DC |
| Output Contact Rating | 30 V DC, 100 mA (inductive load, resistive load) |
DCS Instrumentation and Channel Isolation Architecture
The module executes isolated channel signal processing, ensuring robust galvanic separation boundaries across complex process loops. Internal circuit architectures maintain stable common-mode signal integrity and precise threshold detection for both contact and voltage inputs.
Output signal switching is handled via transistor contacts capable of driving resistive and inductive loads up to 30 V DC and 100 mA, while response timing is governed by fixed internal polling parameters.
Frequently Asked Questions
Q: What are the input signal resistance thresholds for contact status detection?
A: Contact OFF signals require 100 kΩ or more, whereas ON signals require 200 Ω or less, with a minimum current value of 1.25 mA when the contact is short-circuited.
Q: What specifications govern the transistor contact output ratings?
A: The output signal uses a transistor contact supporting inductive and resistive loads rated at 30 V DC and 100 mA, with an output response time of 16 ms or less.
Q: How does the module interface with external field connections?
A: External connections are established using a dedicated cable (KS2), and the hardware is designed to be compatible with ST3 systems.
Field Installation Guidelines
- Mounting: Secure the module firmly into the designated modular rack slot to guarantee proper backplane bus pin engagement.
- Wiring Separation: Route digital input and transistor output signal lines away from high-power distribution cables to prevent electrical noise coupling.
- Shield Grounding: Connect all cable shield drains to the designated grounding bar inside the termination cabinet.
- Verification: Inspect terminal connections and verify signal voltage ranges prior to system energization.
