The Woodward 9905-001 SPM-A Synchronizer is designed to automatically match the frequency, voltage, and phase angle of a generator to a bus before connection. It ensures smooth synchronization and reliable parallel operation of multiple generators.
Specifications
Manufacturer: Woodward
Model: 9905-001
Type: SPM-A Synchronizer Module
Application: Generator synchronization to bus/grid
Voltage Range: 90–150 VAC sensing
Frequency Range: 50–60 Hz
Control Output: Analog signal for governor and exciter adjustment
Response Time: Fast correction for synchronization accuracy
Mounting: Panel or rack installation
Operating Temperature: -40°C to +85°C
Weight: ~1.0 kg
Features
Automatic Synchronization: Matches generator frequency, voltage, and phase angle to bus.
Precise Control: Provides accurate signals to governor and exciter for smooth operation.
Industrial Reliability: Built for continuous use in demanding environments.
Flexible Integration: Compatible with a wide range of generator systems.
Fast Response: Ensures minimal delay in synchronization process.
Durable Design: Rugged construction for long-term performance.
