The Woodward 8200-226 is a high-performance servo position controller module designed for precise actuator and valve control in industrial automation and turbine systems. It delivers accurate positioning, fast response, and robust communication for safety-critical applications.
Specifications
Manufacturer: Woodward
Model: 8200-226
Type: Servo Position Controller (SPC)
Rated Power: 40 kW
Rated Voltage: 400 VAC
Rated Speed: 3000 rpm
Peak Torque: 200 Nm
Control Accuracy: ±0.01%
Input Voltage: 12 VDC or 24 VDC
Output Signal: 0–10 VDC or 0–20 mA
Max Output Current: 2 A
Operating Temperature: -40…85 °C
Dimensions: 400 × 300 × 200 mm
Protection Class: IP65
Communication Interfaces: RS-232, RS-485, Ethernet
Compliance: MIL-STD-202G, EN61326-1, EN61006-2, UL 508
Features
High Precision: Advanced servo control technology for critical applications
Versatile Control Modes: Supports position, speed, and torque loop control
Robust Reliability: Modular and redundant design ensures stable operation
Safety Functions: Over-voltage, over-current, and short-circuit protection
Flexible Integration: Multiple communication protocols for easy system connectivity
Industrial Applications: Ideal for valve control in chemical, power generation, and oil & gas industries
