VE4006P2 | Emerson DeltaV | M-Series Serial Interface Card

Product Description

The DeltaV VE4006P2 M-Series Serial Interface Card provides reliable serial communication for process automation systems. With dual-port capability and broad protocol support, it ensures seamless integration of external devices into DeltaV control environments.

Technical Specifications

• Product Number: VE4006P2

• Series: DeltaV M-Series

• Type: Serial Interface Card with simplex terminal block

• Ports: 2 (RS232, RS422/485 half duplex, RS422/485 full duplex)

• Data Sets per Card: 32 (16 per port)

• Isolation: Each port isolated from system and from each other; external grounding required

• Baud Rates Supported: 300, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200

• Parity Options: Even, Odd, None

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

• Storage Temperature: -40°C to +85°C (-40°F to +185°F)

• Protection Rating: IP20

• Relative Humidity: 5–95%, non-condensing

• Shipping Weight: ~2 kg

Application Scenarios

• Integration of external serial devices into DeltaV automation systems

• Industrial environments requiring multiple communication protocols

• Process control systems needing isolated and configurable serial ports

FAQ

Q: How many data sets can be configured per card? A: Up to 32 data sets, with 16 per port.

Q: Are the ports isolated? A: Yes, each port is isolated from the system and from each other, but external grounding is required.

Q: What communication standards are supported? A: RS232, RS422/485 half duplex, and RS422/485 full duplex.
