TSXP572634M | Schneider | Unity Processor

Product Description

The Schneider TSXP572634M Unity Processor is a high-performance controller within the Modicon Premium automation platform. Designed for complex industrial applications, it offers extensive I/O capacity, advanced communication options, and optimized execution speeds. With support for Unity Pro software, this processor ensures seamless integration into modern automation systems.

Main Features

• Product Range: Modicon Premium automation platform

• Component Type: Unity Processor

• Software: Unity Pro

• Concept: Transparent Ready

System Capacity

• Number of Racks: Up to 16 (4/6/8 slots, 8/12 slots)

• Total Slots Supported: 64, 96, or 128 depending on configuration

• Discrete I/O Capacity: 1024 points

• Analogue I/O Capacity: 80 points

• Application-Specific Channels: 24

• Process Control Channels: 10–30 simple loops

• Communication Modules Supported: 1–4

Communication Interfaces

• Serial Link: Non-isolated RS485, 2 female mini DIN connectors, 19.2 kbit/s

• Ethernet TCP/IP: RJ45 connector, 10BASE-T/100BASE-TX

Memory & Storage

• Internal RAM (without PCMCIA): 160 kB program + data

• Internal RAM (with PCMCIA): 160 kB data, 768 kB program

• PCMCIA Card: 16 MB additional data storage

• Object Areas:

  • 64 %KWi constant words

  • 64 %MWi internal words

  • 64 kB unlocated internal data (DFB/EFB blocks)

  • 8132 %Mi located internal bits

Performance

• Execution Time per Instruction:

  • Boolean: 0.19 µs (no PCMCIA), 0.21 µs (with PCMCIA)

  • Word/Fixed Arithmetic: 0.25 µs (no PCMCIA), 0.42 µs (with PCMCIA)

  • Floating Point: 1.75–2.6 µs (with or without PCMCIA)

• Instruction Throughput:

  • 4.76 Kinst/ms (100% Boolean, no PCMCIA)

  • 3.7 Kinst/ms (100% Boolean, with PCMCIA)

  • 2.53–3.71 Kinst/ms (mixed Boolean + arithmetic)

• System Overhead: 0.3 ms fast task, 1 ms master task

Local Signalling

• Ethernet TCP/IP Port Ready: Green LED (RUN)

• Processor Running: Green LED (RUN)

• Collision Detection: Red LED (COL)

• Ethernet Fault: Red LED (ERR)

• I/O Fault: Red LED (I/O)

• Processor/System Fault: Red LED (ERR)

• TER/AUX Port Activity: Yellow LED (TER)

• Ethernet Diagnostics: Yellow LED (STS)

• Reception Activity: Yellow LED (RX)

• Transmission Activity: Yellow LED (TX)

Electrical & Physical

• Current Consumption: 1650 mA at 5 V DC

• Module Format: Double

• Weight: 0.042 kg

Environmental Ratings

• Operating Temperature: 0–60 °C

• Storage Temperature: -25–70 °C

• Humidity: 10–95 % (operation), 5–95 % (storage)

• Altitude: 0–2000 m

• Protection: TC treatment, IP20, Pollution degree 2

Application Scenarios

• Large-scale automation requiring high I/O density

• Process industries with multiple control loops

• Systems needing Ethernet TCP/IP connectivity and modular expansion

FAQ

Q: What is the maximum program memory with PCMCIA support? A: Up to 768 kB program memory plus 16 MB additional storage.

Q: How many racks can be connected? A: Up to 16 racks, supporting 64–128 slots depending on configuration.

Q: Does the processor support Ethernet communication? A: Yes, via RJ45 connector supporting 10BASE-T/100BASE-TX.
