TSXMRPC002M | Schneider | SRAM Memory Extension Module

Product Description

The TSXMRPC002M from Schneider Electric’s Modicon Premium automation platform is a configurable SRAM memory extension module designed to expand application and file storage capacity for Premium processors. It provides reliable data storage and enhanced flexibility for demanding automation tasks.

Main Features:

• Series: Modicon Premium

• Type: SRAM Memory Extension Module

• Designation: Configurable application/file memory extension

• Category: Separate accessory part

• Destination: Processor slot

Compatibility:

• Compatible Processors: TSX570…TSX576, TSX57C, TSXPCI572/3

• Slot Assignment: Slot 0

Memory Specifications:

• Memory Type: SRAM

• Capacity:

  • 1856 kB for data storage

  • 192…2048 kB for application programs

Physical Characteristics:

• Net Weight: 0.076 kg (0.168 lb US)

Application Scenarios

The TSXMRPC002M is ideal for Modicon Premium processors requiring additional SRAM capacity for complex automation applications. It is widely used in manufacturing, energy, and process industries where extended memory is essential for program execution and file storage.

FAQ

Q: What processors are compatible with TSXMRPC002M? A: It supports TSX570 to TSX576, TSX57C, and TSXPCI572/3 processors.

Q: What is the memory capacity? A: It provides up to 1856 kB for data storage and 192–2048 kB for application programs.

Q: Where is the module installed? A: It is designed for Slot 0 in the processor.
