The Honeywell TC-IAH061 Experion Analog Input Module delivers six galvanically isolated input channels for precise signal acquisition in process automation systems. With advanced diagnostics, robust immunity to interference, and reliable performance across harsh environments, it ensures accurate monitoring and seamless integration into Honeywell Experion platforms.
Technical Specifications:
Model: TC-IAH061
Manufacturer: Honeywell
Type: Experion Analog Input Module
Number of Channels: 6 galvanically isolated inputs
Open Circuit Detection:
Voltage: Upscale reading
Current: Zero scale reading
Typical OC Detection Time:
Voltage: 5 seconds
Current: 1 second
Channel Bandwidth: 0–15 Hz (-3 dB)
RFI Immunity: Error < 2.0% of range at 10 V/m, 27–1000 MHz
Vibration: 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz)
Airborne Contaminants: ISA-S71.04-1985 Class G3
Key Features:
Six isolated analog input channels for reliable measurement
Fast update rate (25 ms) for real-time monitoring
Strong RFI immunity for stable operation in noisy environments
Integrated open-circuit detection for enhanced diagnostics
Application Scenarios: Ideal for Honeywell Experion systems in industries such as oil & gas, chemical processing, and power generation. Suitable for monitoring temperature, pressure, and flow signals with high accuracy.
FAQ:
Q: What type of terminal block is required? A: The module uses TC_TBNH 20-position terminal blocks.
Q: How does the module handle open circuit detection? A: Voltage inputs show upscale readings, while current inputs show zero scale readings.
