The ICS Triplex T9832 analogue input module is part of Rockwell’s AAdvance safety controller platform. It is designed for high‑integrity applications where reliability and fault tolerance are critical. The moduleprovides 16 configurable analogue channels, supporting multiple signal types such as current, voltage, RTD, and thermocouples.
Key Features
16 configurable analogue I/O channels
Signal support: 4–20 mA current loops, 0–10 V voltage, RTD, thermocouples
16‑bit resolution, ±0.1% accuracy
Triple Modular Redundancy (TMR) for fault tolerance
SIL 3 certified (IEC 61508)
Advanced diagnostics with LED status indicators
Isolation between channels and system bus
Overvoltage and short‑circuit protection
Compact design, lightweight (~200 g)
Application Scenarios
The T9832 is widely used inoil & gas, petrochemical plants, power generation, and transportation systems, where continuous operation and safety compliance are essential. It is ideal for monitoring temperature, pressure, and flow signals in process automation systems that demand high availability.
FAQ
Q: Is the T9832 only an input module? A: No, it is a configurable analogue I/O module, meaning channels can be set as inputs or outputs.
Q: Why is it suitable for safety systems? A: Its TMR architecture and SIL 3 certification provide fault tolerance and compliance with international safety standards.
Q: What types of signals are supported? A: Current (4–20 mA), voltage (0–10 V), RTD, and thermocouple inputs.
