Schneider Modicon X80 | BMXAMM0600 | Mixed Analog I/O Module

Product Description

The BMXAMM0600 mixed analog I/O module from Schneider Electric’s Modicon X80 series combines four analog inputs and two analog outputs in a single unit. It supports multiple current and voltage ranges, ensuring flexible integration into industrial automation systems. With high resolution, digital filtering, and robust protection, it delivers precise measurement and reliable signal conversion.

Main Features:

• Series: Modicon X80

• Type: Mixed Analog I/O Module

• Electrical Connection: 20-way connector

• Isolation: Non-isolated channels

• Analog Inputs: 4 channels (0…20 mA, 4…20 mA, ±10 V, 0…10 V, 0…5 V, 1…5 V)

• Analog Outputs: 2 channels (0…20 mA, 4…20 mA, ±10 V)

Input Specifications:

• Resolution: 12–14 bits depending on range

• Overload Protection: ±30 mA (current), ±30 V (voltage)

• Input Impedance: 250 Ω

• Conversion Accuracy: ≤ 0.25–0.5 % of full scale depending on signal type and temperature

• Temperature Drift: 30–50 ppm/°C for inputs

• Filtering: First-order digital filter (firmware)

• Read Cycle Time: 1 ms + 1 ms per channel; 5 ms nominal for 4 channels

• Crosstalk Attenuation: ≥ 70 dB

• Common Mode Rejection: ≥ 80 dB

• Isolation Voltage: 1400 V DC (channels/ground, channels/bus), 750 V DC (I/O groups)

Output Specifications:

• Resolution: 11–12 bits depending on range

• Conversion Time: ≤ 2 ms

• Maximum Output Values: ±11.25 V (voltage), up to 24 mA (current)

• Temperature Drift: 100 ppm/°C

• Fallback Mode: Predefined or configurable

Performance and Reliability:

• MTBF: 1,400,000 hours

• Calibration: Factory calibrated outputs, internal recalibration for inputs

• Power Consumption: 2.6–3.2 W (24 V DC), 0.35–0.48 W (3.3 V DC)

• Current Consumption: 240 mA at 3.3 V DC

• Net Weight: 0.155 kg

Status Indicators:

• RUN LED (green): Module operating

• Channel LEDs (green): Diagnostics per channel

• ERR LED (red): Module error

• I/O LED (red): I/O status

Environmental Characteristics:

• Protection Rating: IP20

• Storage Temperature: -40…85 °C

• Operating Temperature: 0…60 °C

• Humidity: 5…95 % at 55 °C (non-condensing)

• Vibration Resistance: 3 gn

• Shock Resistance: 30 gn

• Altitude: 0…2000 m; up to 5000 m with derating

• Compliance: 2014/35/EU Low Voltage Directive, 2014/30/EU EMC Directive

• Certifications: CE, RCM, CSA, EAC, UL, Merchant Navy

• Standards: IEC 61010-2-201, IEC 61131-2, UL 61010-2-201, CSA C22.2 No 61010-2-201

Application Scenarios

The BMXAMM0600 is ideal for automation systems requiring both analog input measurement and analog output control. It is widely used in process industries, manufacturing, and energy systems where precise signal acquisition and conversion are critical.

FAQ

Q: How many analog channels does BMXAMM0600 provide? A: It offers 4 analog inputs and 2 analog outputs.

Q: What signal ranges are supported? A: Current (0…20 mA, 4…20 mA) and voltage (±10 V, 0…10 V, 0…5 V, 1…5 V).

Q: Is the module factory calibrated? A: Yes, outputs are factory calibrated, while inputs are internally recalibrated.
