The Schneider Electric Modicon Quantum 110CPU72200 is a high-performance central processing unit designed for the Modicon Quantum automation platform. This controller is engineered to handle complex discrete logic and regulatory control loops, making it suitable for demanding industrial applications such as power generation, petrochemical processing, and large-scale mining infrastructure. By providing rapid logic execution and robust system coordination, the 110CPU72200 helps maintain operational stability and minimize process downtime.
Features
High-speed microprocessor optimized for ladder logic, structured text, and function block execution.
Integrated communication support for Modbus RS232 and Modbus Plus networking.
Comprehensive fault-diagnostic routines for continuous monitoring of processor, memory, and backplane bus integrity.
Scalable architecture supporting extensive local and remote I/O configurations.
Designed for seamless integration into standard Modicon Quantum backplanes.
Applications
This CPU module is widely utilized in critical infrastructure environments requiring high reliability, including:
Petrochemical and chemical refining processes.
Power generation and distribution control systems.
Large-scale mining and material handling operations.
Complex multi-axis motion control and regulatory loop management.
Technical Specifications
Model
110CPU72200
Brand
Schneider Electric
Processor Clock Speed
20 MHz
Memory Capacity
512 KB Internal RAM
Power Consumption
5 VDC, 1250 mA (via backplane)
Communication Ports
Modbus RS232, Modbus Plus
Operating Temperature
0 to 60 deg C
Storage Temperature
-40 to 85 deg C
Relative Humidity
95% (non-condensing)
Slot Width
1 Single Slot
Installation Guidelines
Ensure the system power is disconnected before installing or removing the CPU module from the Quantum backplane.
Verify that the module is fully seated and the locking tabs are engaged to ensure a secure connection to the backplane bus.
Maintain adequate clearance around the module to facilitate proper airflow and cooling within the enclosure.
Follow standard ESD precautions when handling the module to prevent damage to internal electronic components.
Ensure that communication cables are properly shielded and routed away from high-voltage or high-EMI sources to maintain signal integrity.
FAQ
What communication protocols does the 110CPU72200 support?
The module features integrated support for Modbus RS232 and Modbus Plus, enabling peer-to-peer networking and connectivity with HMIs and SCADA systems.
Is this module compatible with standard Quantum backplanes?
Yes, the 110CPU72200 is designed to mount directly into standard Modicon Quantum backplanes, occupying a single slot.
