The Schneider Electric TSXP57024M is a high-density digital I/O module designed for the Modicon Premium automation platform. This module provides 32 channels of 24 VDC logic, facilitating robust signal processing and interface capabilities for industrial control systems. Engineered for reliability in demanding environments, it ensures efficient data exchange between field devices and the PLC backplane.
Features
32-channel digital I/O configuration for high-density applications.
Nominal operating voltage of 24 VDC with a stable range of 19.2 to 30 VDC.
Field-to-logic isolation rated at 1500 VAC to protect internal circuitry from field-side electrical surges.
Optimized power consumption with 120 mA typical draw from the 5 VDC backplane.
Compact design suitable for standard Modicon Premium rack mounting.
Technical Specifications
Product Model
TSXP57024M
I/O Type
32-channel Digital Logic
Nominal Voltage
24 VDC
Operating Range
19.2 to 30 VDC
Isolation
1500 VAC (Field-to-Logic)
Backplane Current
120 mA @ 5 VDC
Max Field Power
~224 mA @ 24 VDC
Tariff Code
8537101190
Installation Guidelines
Ensure the PLC rack is powered down before installing or removing the module to prevent electrical damage or system faults.
Verify that the module is correctly seated in the backplane slot and secured using the integrated locking mechanisms.
Use appropriate shielded cabling for field I/O connections to minimize electromagnetic interference (EMI).
Maintain proper ventilation within the control cabinet to ensure the module operates within its specified temperature range.
Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive electronic components.
FAQ
What is the primary function of the TSXP57024M? This module serves as a 32-channel digital I/O interface for the Schneider Electric Modicon Premium PLC series, allowing for the connection of 24 VDC field devices.
What is the isolation rating for this module? The module provides 1500 VAC field-to-logic isolation, ensuring robust protection between the field wiring and the PLC processor.
