- Schneider Electric 140CPU53414A Modicon Quantum CPU Processor Module
Sale
Schneider Electric 140CPU53414A Modicon Quantum CPU Processor Module
No reviews
In stock!
- Part Number: 140CPU53414A
- Brand: Schneider Electric
- Type: Modicon Quantum CPU Processor Module
- Dimensions: 4x10.5x25cm
- Country of Origin: France
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
| Communication Protocols |
|
| Controller Design |
|
Product Description
The Schneider Electric 140CPU53414A, also cataloged as the 140CPU53414A CPU Processor Module, operates as a dedicated hardware component for high-performance application execution within Modicon Quantum automation networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 140CPU53414A |
| Brand | Schneider Electric |
| Origin | France / Global Standard Architecture |
| Weight | 0.701 kg (1.545 lb) net module mass |
| Dimensions | 53 mm x 168 mm x 317 mm (W x H x D) |
| Operating Temp | 0 to 60 deg C (32 to 140 deg F) |
| Power Consumption | 5 W maximum thermal dissipation (1.25 A at 5 V DC bus requirement) |
| Processor Type | Intel 80586 DX (Intel 586) with integrated math coprocessor |
| Processor Clock Speed | 133 MHz |
| Internal Memory Capacity | 2.7 MB total internal memory (up to 4 MB SRAM allocation) |
| Onboard Communication Ports | 2 x Modbus (RS-232, 9-pin D-shell) / 1 x Modbus Plus (RS-485) |
| Hardware Security | Integrated mechanical front panel Key Switch |
| Battery Backup System | 3 V Lithium battery (1200 mAh capacity, 10 years shelf life) |
Modicon Quantum Platform Backplane Architecture
The 140CPU53414A architecture utilizes an Intel 586 core running at 133 MHz designed to track system variables across backplane bus communication velocity Licences. Serving as the primary computational processor on the Quantum frame, the card transfers complex math data over Profinet / EtherNet/IP deterministic networks via external network gateways connected directly to the backplane communication loop.
The internal processing matrix supports automated I/O density scaling routines by managing up to 6 local modules alongside large remote I/O drop networks consisting of up to 31 distinct drop adaptors. The computational framework tracks complex arithmetic formulas via the integrated math coprocessor, keeping typical logic solve execution times between 0.1 ms/k and 0.5 ms/k. This high-end processor maintains real-time control synchronicity for 64 inputs and 64 outputs locally while supporting dual-processor Hot Standby tracking logic and complete software configuration firmware flash compatibility across legacy Concept, Modsoft, and ProWorx engineering utilities.
Frequently Asked Questions
Q: What specific hardware backup and memory behavior occurs when the main system power supply drops?
A: The module relies on an onboard 3V lithium battery to maintain the volatile SRAM application code and system configuration variables. When backplane power cuts out, the memory switches immediately to the battery circuit, retaining the registers for up to the full 1200 mAh service duration.
Q: How does the mechanical key switch located on the front panel affect the processor firmware status?
A: The integrated key switch serves as a mechanical memory protection lock. When set to the write-protect position, it physically blocks remote configuration changes, memory overwrites, or application download commands from the engineering software, isolating the runtime code from unintended modification.
