Schneider 171CCC96020 Processor Adapter

Product Description

The 171CCC96020 processor adapter is part of the Schneider Electric Modicon Momentum automation platform. Designed for modular control systems, it provides robust processing capability, flexible memory allocation, and compatibility with multiple programming environments.

Key Features

• Product Range: Modicon Momentum automation platform

• Type: M1/M1E processor adapter

• Supported Software: Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, ProWORX 32

• Communication Protocol: Modbus

• Processor Architecture: X86 (Intel, AMD)

• Clock Frequency: 32 MHz

• Discrete I/O Capacity: 8192 inputs / 8192 outputs

• Register I/O Capacity: 26048 inputs / 26048 outputs

• I/O Limit: Maximum 8192 points

• I/O Words per Drop: 128 (Concept), 80 (ProWORX)

• Memory:

  • 512 kB Flash

  • 512 kB RAM

  • Program storage: 18 kB LL984, 240 kB IEC

  • Data storage: 24 kB

• Material: Lexan housing

• Word Length: 16-bit

• Rated Supply Voltage: 5 V DC ±5%

• Power Source: Momentum I/O base

• Instruction Execution Time: 1 ms per k-instruction

• Ports:

  • 1 I/O bus

  • 1 RS232C non-isolated

Environmental Ratings

• Operating Temperature: 0–60 °C

• Storage Temperature: -40–85 °C

• Relative Humidity: 5–96% non-condensing

• Altitude: ≤ 2000 m

• Shock Resistance: ≤ 15 gn peak, 11 ms half-sine acceleration

• Vibration Resistance: 0.75 mm displacement amplitude, 1 gn

Compliance & Certifications

• CE Marking

• UL Listed

• cUL Certified

• FM Class 1 Division 2

• NEMA Type 250

• TC protective treatment

Physical Characteristics

• Net Weight: 0.042 kg

Application Scenarios

This processor adapter is ideal for distributed control systems, modular automation setups, and industrial environments requiring scalable I/O management. It supports multiple programming platforms, making it versatile for legacy and modern control strategies.

FAQ

Q: Which programming environments are supported? A: Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, and ProWORX 32.

Q: What is the maximum I/O capacity? A: Up to 8192 discrete inputs and 8192 discrete outputs.

Q: Does it support Modbus communication? A: Yes, Modbus protocol is supported natively.
