The General Electric IS200TAMBH1ACB is an Acoustic Monitoring Terminal Board designed for use within the Mark VIe control system architecture. This terminal board serves as a critical interface for acoustic monitoring applications, facilitating the signal conditioning and routing required for high-precision monitoring tasks in industrial environments. It is engineered to support the integration of acoustic sensors into the broader control system, ensuring reliable data acquisition and system performance.
Features
Designed for seamless integration with the Mark VIe control platform.
Supports 4-20 mA current input circuits for acoustic sensor connectivity.
Provides a regulated +24 V DC power supply for field instrumentation.
Robust construction suitable for demanding industrial monitoring environments.
Compatible with IS200TAMBH1A spare model configurations.
Technical Specifications
Product Model
IS200TAMBH1ACB
Spare Model
IS200TAMBH1A
Manufacturer
General Electric
Power Supply
+24 V DC
Input Type
4-20 mA circuits
Operating Temperature
0 degC to 60 degC
Storage Temperature
-40 degC to 85 degC
Humidity
10% to 95% RH (non-condensing)
Installation Guidelines
Ensure the control system power is completely disconnected before attempting to install or remove the terminal board.
Handle the module using proper ESD (Electrostatic Discharge) mitigation techniques to prevent damage to sensitive electronic components.
Verify that the terminal board is securely seated in the designated rack slot to ensure proper backplane communication.
Ensure all field wiring is routed correctly, keeping signal cables separated from high-voltage power lines to minimize EMI/RFI interference.
Confirm that the +24 V DC supply voltage is within the specified operating range before energizing the system.
FAQ
What is the primary function of the IS200TAMBH1ACB?
This board is an acoustic monitoring terminal board used in GE Mark VIe systems to process and interface signals from acoustic sensors, typically used for monitoring equipment health and vibration characteristics.
Is this board compatible with the IS200TAMBH1A?
Yes, the IS200TAMBH1ACB is designed to be compatible with the IS200TAMBH1A spare model configuration.
What are the environmental requirements for this module?
The module should be operated in an environment with a temperature range of 0 degC to 60 degC and a non-condensing humidity level between 10% and 95%.
