The Emerson KL4201X1‑BA1 DeltaV CHARM Baseplate provides the mechanical and electrical foundation for CHARM I/O cards in DeltaV distributed control systems. It ensures secure installation, reliable signal distribution, and flexible integration of analog and digital I/O modules.
Specifications
Manufacturer: Emerson
Product Number: KL4201X1‑BA1
Product Type: DeltaV CHARM Baseplate
System Compatibility: DeltaV CHARM I/O subsystem
Supported Modules: Analog and digital CHARM I/O cards
Slots: Multiple CHARM positions per baseplate
Communication Backbone: DeltaV CHARM bus interface
Mounting: DIN rail installation
Operating Voltage: 24 VDC nominal
Operating Temperature: –20 °C to +60 °C
Protection: Industrial‑grade design with secure connectors
Weight: Approx. 0.45 kg
Features
System Backbone: Provides mechanical and electrical base for CHARM modules
Flexible Integration: Supports multiple analog and digital CHARM I/O types
Reliable Communication: Ensures stable data transfer within DeltaV systems
Compact Design: DIN rail mounting for efficient installation
Industrial Durability: Built for continuous operation in harsh environments
Easy Maintenance: Hot‑swappable CHARM modules for reduced downtime
