The Emerson KJ3201X1-EA1 Redundant Discrete Terminal Block is engineered to provide secure and reliable connectivity for discrete signals in DeltaV distributed control systems. Designed with redundancy, this terminal block enhances system reliability by reducing single-point failure risks, ensuring continuous operation in mission-critical automation environments.
Technical Specifications
Voltage Rating: 30 VDC
Maximum Current: 1 A per channel, 3 A per card
Operating Temperature: 0 °C to 60 °C
Shock Resistance: 10 g, half-sine wave, 11 ms duration
Vibration Endurance:
1 mm peak-to-peak, 5–16 Hz
0.5 g, 16–150 Hz
Airborne Contaminants: ISA-S71.04-1985, Class G3
Relative Humidity: 5–95%, non-condensing
Protection Rating: IP20
Application Highlights
Provides redundant discrete signal connectivity for Emerson DeltaV systems
Enhances reliability by minimizing single-point failure risks
Suitable for environments with vibration, shock, and airborne contaminants
Designed for continuous process industries requiring robust discrete signal distribution
