The GE IS230TCISH6C, also cataloged as the IS230TCISH6C DIN Rail I/O Module, serves as a PCB-based discrete interface with relay outputs and hardware filtering for turbine and plant control applications within Mark VIe distributed control systems.
Hardware Specifications
Parameter
Specification
Model
IS230TCISH6C
Brand
GE (General Electric)
Origin
USA
Weight
Not specified
Dimensions
Not specified
Operating Temp
-30 to +65 deg C
Power Consumption
Not specified
Mounting Option
DIN Rail
Technology
Surface-mount
Number of Relays
12
Input Filter
Hardware filter, 4 ms
Product Type
PCB
Backplane Bus Communication Velocity Licenses
The IS230TCISH6C integrates into the Mark VIe backplane with deterministic communication protocols. Backplane bus communication velocity licenses ensure predictable cycle timing across distributed I/O packs. Firmware flash compatibility allows synchronized updates across modules. I/O density scaling is achieved by clustering modules, while passive circuits on terminal boards provide continuity of field wiring even during module replacement.
Frequently Asked Questions (FAQ)
Q: Can the IS230TCISH6C terminal blocks be removed with wiring attached? A: Yes. Terminal blocks can be detached with field wiring intact, allowing passive circuit replacement without rewiring.
Q: What is the filtering capability of the module? A: It employs a hardware input filter with a 4 ms response to suppress transient noise.
Q: How many relays are integrated on the board? A: The module includes 12 relays, supporting discrete control functions.
Field Installation Guidelines
Mount securely on DIN rail to ensure mechanical stability.
Maintain separation between relay wiring and low-level signal circuits.
Ensure grounding of shielded cables to minimize interference.
Verify input filter operation during commissioning to confirm suppression of transient signals.
Confirm surface-mount solder integrity before installation in vibration-prone environments.
