The General Electric IS200EDEXG1A is an Exciter De-Excitation Board designed for use within the EX2100 Excitation Control System. This component serves as a critical module for managing the de-excitation process of the generator exciter, ensuring controlled and safe shutdown sequences for power generation equipment. As part of the Mark VIe and EX2100 ecosystem, it provides reliable performance in demanding industrial environments.
Features
Designed specifically for the GE EX2100 Excitation Control System architecture.
Facilitates precise control over exciter de-excitation functions.
Robust construction suitable for high-reliability power generation applications.
Wide operating temperature range for installation in various control room or cabinet environments.
Technical Specifications
Model
IS200EDEXG1A
Manufacturer
General Electric
Series
EX2100
Power Input
24 V DC
Current Draw
<= 0.5 A @ 24 V
Gate Drive
+125 V DC
Isolation
500 V DC
Operating Temperature
-40 degC to +85 degC
Storage Temperature
-55 degC to +90 degC
Humidity
5 to 95 % RH (non-condensing)
Installation Guidelines
Ensure all power is disconnected from the EX2100 cabinet before attempting to install or remove the IS200EDEXG1A module.
Handle the board using proper ESD (Electrostatic Discharge) mitigation techniques to prevent damage to sensitive electronic components.
Verify that the board is correctly seated in its designated slot within the rack assembly.
Ensure that all wiring connections are secure and routed away from high-voltage interference sources to maintain signal integrity.
Maintain adequate ventilation around the control cabinet to ensure the module operates within its specified temperature range.
FAQ
What system is the IS200EDEXG1A compatible with?
This board is a component of the General Electric EX2100 Excitation Control System.
What is the primary function of this board?
The IS200EDEXG1A acts as an Exciter De-Excitation Board, responsible for managing the safe reduction or removal of excitation current during system shutdown or fault conditions.
Can this board operate in extreme temperatures?
Yes, the module is rated for an operating temperature range of -40 degC to +85 degC, making it suitable for a variety of industrial environments.
