The General Electric IC660TBD022 is a high-performance Genius Block I/O module designed for industrial automation control systems. As part of the GE Genius I/O series, this module provides reliable 16-circuit discrete input and output functionality, facilitating seamless communication between field devices and the primary controller. It is engineered to operate within a 24 VDC environment, ensuring robust performance in demanding industrial settings.
Features
16-circuit discrete I/O configuration for versatile field device integration.
Designed for 24 VDC nominal operation with an operating range of 18 to 30 VDC.
High-level electrical isolation of 1500 Volts for 1 minute between blocks to protect system integrity.
Supports a power supply dropout time of 10 milliseconds, enhancing system stability during minor power fluctuations.
Optimized for integration within the GE Genius I/O distributed control architecture.
Technical Specifications
Product Model
IC660TBD022
Series
Genius I/O
Circuit Count
16 (Discrete I/O)
Rated Voltage
24 VDC
Operating Voltage
18 to 30 VDC
Maximum Ripple
10%
Power Supply Dropout Time
10 ms
Heat Dissipation (Max)
68.8 Watts (at 16 outputs, 2 Amps each)
Isolation
1500 Volts (1 minute)
Installation Guidelines
Ensure the power is disconnected before installing or removing the module from the I/O rack or mounting surface.
Maintain proper ventilation to manage heat dissipation, as the module can dissipate up to 68.8 Watts under full load.
Use shielded cabling for I/O connections to minimize electromagnetic interference (EMI) in industrial environments.
Ensure the module is securely mounted to the designated backplane or DIN rail to prevent vibration-related connection issues.
Observe correct polarity when wiring 24 VDC power inputs to prevent damage to the module circuitry.
Handle with standard ESD (Electrostatic Discharge) precautions to protect internal electronic components.
FAQ
What is the primary function of the IC660TBD022?
The IC660TBD022 is a discrete I/O block that interfaces field sensors and actuators with a GE Genius I/O network, allowing for distributed control and monitoring.
What is the maximum heat dissipation for this module?
The maximum heat dissipation is 68.8 Watts, which occurs when all 16 outputs are energized at 2 Amps each.
Is this module compatible with standard 24 VDC systems?
Yes, it is designed for a nominal 24 VDC supply, with an acceptable operating range between 18 and 30 VDC.
