The GE Fanuc IC200ALG263 VersaMax Analog Input Module provides reliable analog signal acquisition for VersaMax PLC systems. With multiple input channels, strong isolation, and precise measurement capability, it ensures stable integration of field signals into industrial automation processes.
Specifications
Manufacturer: GE Fanuc
Model Number: IC200ALG263
Product Type: VersaMax Analog Input Module
Channels: 8 differential analog input channels
Input Signal Range: ±10 VDC, 0–20 mA, 4–20 mA (configurable)
Resolution: 12‑bit
Update Rate: 0.4 ms typical
Isolation: 1500 V RMS field‑to‑logic isolation
Indicators: FLD PWR LED (field power present), OK LED (backplane power present)
Backplane Current Consumption: 5 V output, 130 mA max
External Supply Voltage Range: +18 to +30 VDC
Dimensions: Approx. 11 cm × 6.68 cm × 5 cm (excluding carrier/connectors)
Shipping Weight: 2 kg
Condition: Brand new
Features
Accurate Signal Acquisition: Supports voltage and current inputs with 12‑bit resolution
Flexible Configuration: Selectable ranges for diverse industrial applications
Strong Isolation: Protects PLC logic from field‑side disturbances
Diagnostic LEDs: Simplifies troubleshooting with clear status indicators
Compact Design: Efficient footprint for VersaMax racks
Industrial Reliability: Built for continuous duty in demanding environments
