The Honeywell TP-OPADP1-200 51305776-100, also cataloged as the TP-OPADP1-200 Operator Advisor Panel, operates as a dedicated hardware component for local alarm monitoring and manual control execution within Experion PKS, Safety Manager, FSC, and TDC 3000 platforms.
Suffix Breakdown & Model Matrix
TP-OPADP1-200: Base hardware model identifier for the Operator Advisor Panel adapter and interface assembly.
51305776-100: Specific 10-digit manufacturing part number designating the physical panel layout, circuit board assembly, and backplane interface integration.
Hardware Specifications
Parameter
Specification
Model
TP-OPADP1-200 51305776-100
Brand
Honeywell
Origin
USA
Weight
Standard Operator Panel Weight
Dimensions
Standard Cutout Panel-Mount Footprint
Operating Temp
0 to +60 deg C
Power Consumption
Powered via Control System Backplane / Local Feed
Display Interface
Real-Time Diagnostic & Alarm Status Indicators
System Compatibility
Experion PKS, Safety Manager, FSC, TDC 3000
Mounting Type
Industrial Panel Flush-Mount
Channel Isolation & Process Control Protocol Execution
Engineered for local human-machine interface (HMI) execution, the TP-OPADP1-200 51305776-100 provides direct data visualization and alarm processing across primary control networks. Internal communication lines incorporate channel-to-channel isolation to decouple local operator interface circuits from high-frequency industrial noise on main DCS backplane buses. Operating in tandem with 4-20 mA HART loops and safety logic systems, the panel maintains continuous polling of active field alarms and system health registers without degrading controller execution speed.
Frequently Asked Questions
Q: Which Honeywell control systems natively interface with the TP-OPADP1-200 51305776-100 operator panel?
A: The panel is compatible with Honeywell Experion PKS, Safety Manager, FSC, and legacy TDC 3000 distributed control platforms.
Q: How is the operator panel physically secured in control room enclosures?
A: The module uses standard panel-mount bracket assemblies designed to fit cutouts in console doors or local control cabinets.
Field Installation Guidelines
Cut the cabinet panel opening to specified dimensions and deburr all sheet metal edges prior to panel insertion.
Insert the TP-OPADP1-200 assembly into the panel cutout from the front, ensuring the perimeter environmental gasket is seated flush.
Install and tighten the rear panel-mounting clamps evenly to achieve a secure seal against dust and ingress.
Route ground conductors directly from the panel earth stud to the main cabinet ground bar to prevent static build-up and electrical noise.
Connect communication and power wiring to the designated rear terminal blocks, ensuring proper cable strain relief before energizing system power.
