The Honeywell CC-TUIO11 51306852-175 is a high-density Universal Input/Output Termination Assembly (IOTA) for the Experion PKS Series C system.This unshielded, non-conformal coated terminal block provides the essential physical interface for connecting field wiring to Universal I/O modules, supporting both redundant and non-redundant configurations.
Specifications
Part Number:51306852-175
Model Designation:CC-TUIO11
Channel Capacity:Supports up to 32 universal I/O channels.
Compatibility:Exclusively designed for the CC-PUIX01 Universal I/O module.
Terminal Type:Compression-style screw terminals for secure field wire landing.
Mounting Type:Vertical carrier mounting within a standard Series C cabinet.
Coating:Uncoated (Standard) for use in non-corrosive, controlled environments.
Redundancy:Supports 1:1 module redundancy for high-availability control loops.
Features
Universal Channel Flexibility:Allows each of the 32 channels to be individually configured as Analog Input, Analog Output, Digital Input, or Digital Output.
Simplified Wiring:Consolidates diverse signal types onto a single termination board, significantly reducing cabinet footprint and wiring complexity.
Field-Replaceable Design:Enables the connected I/O module to be swapped or upgraded without disconnecting any field-side wiring.
Robust Signal Routing:Engineered to maintain high signal integrity for 4-20mA loops and discrete signals simultaneously.
Integrated Blown Fuse Detection:Provides clear hardware-level feedback for individual channel power faults to speed up troubleshooting.
