Honeywell CC-TAOX61 Analog Output IOTA Module

Description

The Honeywell CC-TAOX61 is a high-reliability Input Output Termination Assembly (IOTA) designed for the Experion PKS Series C architecture. This component acts as the physical interface between the Analog Output (AO) modules and field wiring, specifically engineered to support redundant configurations while maintaining a compact footprint in the control cabinet.

Specifications

• Model Number: CC-TAOX61
• Part Number: 51308353-125
• IOTA Type: Redundant Analog Output
• Channel Count: 16 channels per assembly

• Size: 6-inch (152 mm) width for high-density mounting
• Signal Compatibility: Supports 4-20 mA DC analog signals
• Communication Support: Full transparency for HART digital signals
• Coating: Available with conformal coating for protection against environmental contaminants

Features

• Redundancy Ready: Specifically designed to host two Analog Output modules, providing seamless failover protection for critical control loops.
• Compact Footprint: The 6-inch width allows for maximum I/O density within the Series C cabinet compared to larger 12-inch versions.
• Integrated HART: Facilitates the pass-through of HART digital data from field instruments to the Experion PKS system for advanced asset management.

• Ease of Maintenance: Features a plug-in design that allows modules to be replaced without disturbing the permanent field wiring connected to the IOTA.
• Robust Terminal Blocks: Equipped with durable screw terminals or compression terminals for secure and long-term field connections.
• Simplified Power Distribution: Distributes redundant 24V DC power to both mounted modules directly through the backplane connection.
