The Honeywell 80363969-150, also cataloged as the 80363969-150 Analog Output Module, operates as a dedicated hardware component for 4-20 mA current signal output generation within Honeywell process control platforms.
Hardware Specifications
Parameter
Specification
Model
80363969-150
Brand
Honeywell
Base Model
80363969-150
Module Type
Analog Output Module
Origin
USA
Weight
0.99 lbs
Dimensions
Standard Controller Slot / Carrier Footprint
Operating Temp
0 to 60 deg C
Power Consumption
Standard Backplane Bus Supply
Output Channels
16 outputs
Output Signal Type
4-20 mA
Category
PLCs/Machine Control, VDC Logic I/O Module
4-20 mA HART Loop Protocol and Channel-to-Channel Isolation
The Honeywell 80363969-150 converts digital control commands into 16 discrete 4-20 mA analog output channels to drive field control valves, positioners, and variable speed drives. Incorporating channel-to-channel isolation networks across all 16 channels, the module suppresses common-mode electrical noise and eliminates ground loop interference between field instrumentation loops and internal system backplane logic. The current generation circuitry operates continuously over 4-20 mA HART loop protocol lines, maintaining stable signal linearity and low output ripple across varying load impedances.
Frequently Asked Questions
Q: What output signal current range does the 80363969-150 module generate?
A: The module delivers a standard 4-20 mA analog output signal across 16 independent channels.
Q: What is the physical shipping weight of the 80363969-150 assembly?
A: The module has a physical weight of approximately 0.99 lbs.
Q: How does the module handle ground potential variations between field loops?
A: Integrated channel-to-channel isolation barriers decouple field wiring loops from backplane logic electronics, preventing ground potential differences from affecting loop performance.
Field Installation Guidelines
Power Disconnection: Ensure that backplane power supplies and external loop driving power sources are fully de-energized prior to inserting or removing the module.
Slot Alignment: Align the module circuit board edges with the top and bottom guide tracks of the designated rack carrier slot. Slide the assembly inward until rear connectors lock securely into the backplane.
Cable Routing & Shielding: Route 4-20 mA output signal cables through dedicated wire ducts away from high-voltage AC conductors. Terminate cable shielding at a single point on the enclosure chassis earth ground.
Convection Clearance: Maintain at least 50 mm of unobstructed clearance above and below the module rack assembly to support natural thermal convection across the operating range.
