- Honeywell 51305829-400 DC Power Supply Module
Sale
Honeywell 51305829-400 DC Power Supply Module
No reviews
In stock!
- Part Number: 51305829-400
- Brand: General Electric
- Type: DC Power Supply Module
- Dimensions: 15.8x10.5x3.5cm
- Country of Origin: USA
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
Product Description
Configured for continuous variable potential regulation in TDC 3000 / Experion PKS networks, the Honeywell 51305829-400 (51305829 DC Power Supply Module) provides direct electrical execution. The chassis-mounted assembly converts a wide-range AC input line into a tightly regulated 24 VDC output rail to energize downstream processing nodes, I/O racks, and field actuators.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51305829-400 |
| Brand | Honeywell |
| Origin | USA |
| Dimensions | Optimized for standard Honeywell control cabinet footprint layouts |
| Operating Temp | -20 to +60 deg C ambient unventilated cabinet tolerance |
| Rated Output Power | 400 W continuous (industrial duty) |
| Nominal Output Voltage | 24 VDC (regulated) |
| Maximum Output Current | 16 to 20 A continuous typical limit |
| Input Voltage Range | 115 to 240 VAC continuous operational input band |
| Line Frequency | 50/60 Hz |
| Conversion Efficiency | Approximately 92% under nominal load conditions |
| Load Regulation | Within +/-1% across the total operational range |
| Power Factor | High power factor design, typically >=0.95 |
| Cooling Concept | Natural convection, fanless passive heat dissipation layout |
| Enclosure Rating | IP20 panel-mount standard |
| Mounting Configuration | DIN-rail or panel mounting compatibility options |
| Protection Functions | Integral over-voltage, over-current, and short-circuit protection loops |
| Product Type | Power Supplies |
Process Control & DCS Instrumentation Interface
- 4-20 mA HART Loop Protocol System Segmentation The 400 W switching matrix partitions its internal power transformer circuits to prevent high-frequency ripple from bleeding into the DC output distribution lines. By limiting output load regulation within +/-1%, the module supplies clean 24 VDC potential to external instruments, ensuring that switching noise does not distort parallel 4-20 mA HART loop protocol signaling tracks.
- Channel-to-Channel Isolation Control Support The power architecture implements heavy dielectric barriers between the primary AC input terminals and the secondary DC output distribution block. This design provides high-grade galvanic separation that bounds external line surges, supporting the channel-to-channel isolation parameters built into downstream analog input modules and host controller backplanes.
Frequently Asked Questions
Q: How does the internal protection logic respond to a sustained field-side short circuit?
A: The module incorporates automatic short-circuit protection circuits. Upon detecting a hard short or an over-current condition that threatens the internal solid-state components, the supply limits current output or drops into a hiccup shutdown mode, resetting automatically once the field fault is cleared.
Q: Can the 51305829-400 module be integrated into redundant power configurations?
A: Yes, the 24 VDC output stages are engineered to support parallel wiring topologies through external diode auctioning or redundancy modules, allowing dual units to share power load matrices across a single system backplane.
