Honeywell 51201420-002 I/O Cable

The Honeywell 51201420-002, also cataloged as the 51201420-002 Cable, operates as a dedicated hardware component for signal transmission between field terminal assemblies and I/O modules within Honeywell control system architectures.

Hardware Specifications

Process Control and DCS Characteristics

• 4-20 mA HART loop protocol: The cable facilitates the propagation of analog loop signals between the terminal assembly and I/O module; proper routing is required to maintain signal fidelity in analog loops.
• FOUNDATION Fieldbus / Profibus PA connectivity: The cable is designed to match the impedance requirements of the control system backplane, ensuring stable data transmission for fieldbus communication segments.
• Channel-to-channel isolation: As a non-shielded interconnect, the cable relies on the inherent design of the control system's I/O modules to manage electrical isolation and signal path integrity between channels.
• Cold junction compensation (CJC): The cable geometry and conductor material are optimized to prevent parasitic thermoelectric effects, ensuring that temperature measurement signals remain accurate during transit to the I/O module.

Frequently Asked Questions

Q: Can this cable be used in high-EMI environments?

A: This cable is non-shielded and is intended for use in controlled cabinet environments. In areas with high electromagnetic interference, ensure the cable is routed within grounded metallic conduit or cable trays to minimize induced noise.

Q: Is this cable compatible with all Honeywell Series 8 FTA configurations?

A: Compatibility is determined by the specific connector interface of the FTA and the associated I/O module. Verify the connector pinout and physical mating requirements of your current I/O configuration before installation.

Field Installation Guidelines

• Mounting: Ensure both ends of the 2 meter cable are fully seated into their respective connectors on the FTA and the I/O module. Secure the locking mechanisms to prevent accidental disconnection due to vibration.
• Grounding: While the cable is non-shielded, ensure the control cabinet and associated racks are bonded to a common protective earth (PE) bus to maintain a consistent reference for all interconnected devices.
• Wiring: Maintain strict separation between this signal cable and high-power AC or DC motor drive conductors. Observe the minimum bend radius requirements during installation to avoid stressing the internal conductors and connector interfaces.
