The Honeywell 08566200A, also cataloged as the 08566200A Measurex Cable Assembly, operates as a dedicated hardware component for signal transmission and interconnection within industrial automation and Measurex control networks.
Hardware Specifications
Parameter
Specification
Model
08566200A
Brand
Honeywell / Measurex
Origin
Global Manufacturing Facility
Weight
System-dependent component mass
Dimensions
Pre-fabricated connectorized cable length
Operating Temp
Standard industrial cabinet range
Power Consumption
Passive interconnect assembly (0 W)
Interface Type
Terminated connectors on each end
Application
Industrial equipment and subsystem signal routing
4-20 mA HART Loop Protocol and Channel Isolation
The cable assembly maintains signal integrity across measurement and control loops through integrated shielding paths designed to minimize electromagnetic interference. Passive signal routing supports 4-20 mA HART loop protocol transmissions and low-voltage signal interfaces without introducing attenuation or phase shift. Channel isolation and continuous shielding architectures protect sensitive analog and digital signals from high-frequency noise within industrial control environments.
Frequently Asked Questions
Q: Does the cable assembly require an active power supply for operation?
A: No. The assembly functions entirely as a passive physical interconnect, routing power and signals between connected automation modules.
Q: Can the cable connectors be modified or replaced in the field?
A: No. Factory-molded termination connectors must remain intact to preserve electrical shielding and mechanical sealing integrity.
Q: How is shielding managed across the cable assembly architecture?
A: Continuous outer shielding and drain paths terminate directly into system grounding hardware to maintain low-impedance EMI protection.
Field Installation Guidelines
Inspect the cable assembly for connector pin damage or jacket abrasion prior to installation within the equipment cabinet.
Route the cable away from high-voltage power conduits and variable frequency drives to prevent electromagnetic interference coupling.
Secure the terminated connectors firmly to the corresponding interface ports, ensuring proper locking or screw engagement.
Verify signal loop continuity and shield ground resistance using a digital multimeter before energizing the control system.
