The HIMA Z7127 analog input module provides accurate acquisition of voltage and current signals for safety-critical applications. It is widely used in emergency shutdown (ESD), fire & gas (F&G) systems, and industrial process monitoring where precise analog measurement is required.
Specifications
Manufacturer: HIMA
Model Number: Z7127
Type: Analog Input Module
Channels: 8 analog input channels
Signal Range: 0–10 V and 4–20 mA
Resolution: High precision (≥12-bit)
Safety Standard: SIL-certified (IEC 61508)
Power Supply: 24 VDC nominal
Dimensions: ~175 × 100 × 22 mm
Weight: ~0.5 kg
Operating Temperature: -20 °C to +60 °C
Diagnostics: Integrated monitoring for signal integrity and fault detection
Warranty: 12 months
Features
High Precision Measurement: Accurate acquisition of voltage and current signals.
Safety-Certified: Suitable for SIL-rated safety instrumented systems.
Versatile Signal Support: Handles both voltage (0–10 V) and current (4–20 mA) inputs.
Diagnostics: Built-in monitoring ensures safe and reliable operation.
Industrial Reliability: Rugged design for continuous use in harsh environments.
System Integration: Compatible with HIMA H41q/H51q safety platforms.
