General Electric IS220PPDAH1B Power Distribution Feedback Module
No reviews
In stock!
- Part Number: IS220PPDAH1B
- Brand: General Electric
- Type: Power Distribution Feedback Module
- Dimensions: 13x8.2x6cm
- Country of Origin: USA
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
Product Description
GE IS220PPDAH1B Power Distribution Feedback Module
Configured for conditioned feedback acquisition within Mark VIe power‑distribution assemblies, the GE IS220PPDAH1B (IS220PPDAH1B Power Distribution System Feedback Module) provides plug‑and‑play diagnostic signal processing and Ethernet‑based IONet communication for JPDS, JPDC, and JPDM host boards.
Suffix Breakdown & Model Matrix
The documentation does not define any suffix variants or sub‑models for IS220PPDAH1B. The board is treated as a single, fixed configuration within the Mark VIe PPDA feedback‑pack family.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS220PPDAH1B |
| Brand | GE Energy |
| Origin | USA |
| Weight | Not specified |
| Dimensions | Not specified |
| Operating Temp | Not specified (follow Mark VIe cabinet limits) |
| Power Consumption | Not specified |
| Series | Mark VIe |
| Product Type | Power Distribution Feedback Module |
| Functional Acronym | PPDA |
| Functional Description | Power Distribution System Feedback |
| PCB Coating | Conformal coating |
| Functional Revision | B |
| Output Voltage | 28 VDC |
| Diagnostic Signals | Two 115/230 VAC analog feedbacks, local ground signal, six fused AC channels, additional feedback paths |
| Self‑Diagnostic Tests | Five power‑up diagnostics (RAM, flash, Ethernet ports, processor hardware) |
| Ground Fault Detection | Supported when paired with JPDE board |
| Mounting Location | JPDS, JPDC, or JPDM boards |
| Connectivity | Ethernet IONet interface; P2 connector for additional feedback signals |
Backplane Bus Communication Velocity Licences
As a GE industrial control module, the IS220PPDAH1B aligns with deterministic Mark VIe timing constraints for power‑distribution feedback. The pack conditions AC and DC diagnostic signals before forwarding them over IONet, ensuring stable propagation windows across cabinet‑level control loops. Its conformal coating and revision‑B hardware maintain compatibility with firmware flash compatibility requirements for Mark VIe controllers. When integrated into plant‑wide networks, the PPDA module supports deterministic behavior across Profinet / EtherNet/IP deterministic networks and aligns with cabinet‑level I/O density scaling for modular power‑distribution assemblies.
Frequently Asked Questions
Q: What does the power‑up self‑test include? A: The pack performs five diagnostics: RAM check, flash memory check, Ethernet port verification, and processor‑hardware validation.
Q: Can additional feedback signals be added? A: Yes. Additional signals can be routed through the P2 connector on the host board.
Q: Does the PPDA require calibration after installation? A: No calibration parameters are defined. The pack operates as a fixed‑function feedback module.
Field Installation Guidelines
- Mount the pack directly onto JPDS, JPDC, or JPDM boards using the designated connector alignment.
- Ensure the Ethernet IONet cable is fully seated to maintain deterministic communication.
- Route AC feedback wiring separately from high‑energy conductors to minimize noise coupling.
- Verify fused AC feedback channels for correct ratings before energizing the cabinet.
- Inspect conformal‑coated surfaces for contamination; debris can create leakage paths under load.
- Confirm grounding practices when using JPDE for ground‑fault detection.
