The GE DS200TCQAG1BHF Extended Analog I/O Board is part of the Mark V turbine control system, designed to deliver reliable analog input/output functionality. With multiple connectors, jumpers, and diagnostic LEDs, it ensures seamless integration and dependable performance in industrial turbine applications.
Technical Specifications
Parameter
Value
Model Number
DS200TCQAG1BHF
Module Type
Extended Analog I/O Board
Manufacturer
GE
Product Range
Mark V / Speedtronic
Condition
Brand New
Dimensions
2.1 × 18.6 × 26.3 cm
Weight
0.22 kg
HS Code
8537101190
System
DCS
Origin
USA
Lead Time
In Stock
MOQ
1
Lifecycle Status
Active (legacy support)
Communication Service
Ethernet router
Connectors
Four 34‑pin, two 40‑pin
Jumpers
Six
LEDs
Six status indicators
Mounting
Six mounting holes with screws/washers
Revisions
H‑rated secondary, F‑rated artwork
Functional Description
The DS200TCQAG1BHF board integrates four 34‑pin connectors, two 40‑pin connectors, and six jumpers, providing flexible connectivity for turbine control systems. Six LEDs offer clear status indication, aiding diagnostics and monitoring.
Its design includes six mounting holes for secure installation in the drive cabinet. Proper handling during installation is critical—washers and screws must be retained to prevent damage, while over‑tightening should be avoided to protect the PCB.
The board incorporates H‑rated secondary functional revisions and F‑rated artwork revisions, ensuring compatibility across different Mark V configurations.
Applications and Compatibility
The GE DS200TCQAG1BHF is essential for Mark V turbine control systems, supporting analog I/O functions in steam, gas, and wind turbines. Its robust design, diagnostic LEDs, and multiple connector options make it a reliable component for maintaining safe and efficient turbine operations.
