The General Electric DS200SDCCG1A, also cataloged as the DS200SDCCG1A Drive Board, operates as a dedicated hardware component for primary drive control and execution within Mark V drive and turbine systems.
Hardware Specifications
Parameter
Specification
Model
DS200SDCCG1A
Brand
General Electric
Origin
Global Manufacturing Facility
Weight
1.00 lbs
Dimensions
Standard Mark V rack form factor
Operating Temp
Standard industrial cabinet range
Power Consumption
Backplane-supplied low voltage logic power
Board Type
Primary Drive Controller Board
System Compatibility
Mark V Platform
Profinet / EtherNet/IP Deterministic Networks, I/O Density Scaling, and Firmware Flash Compatibility
The primary drive controller manages high-speed execution loops across deterministic networks, supporting precise I/O density scaling for complex industrial drive control topologies. Firmware flash compatibility enables direct updating of control algorithms and operational parameters through system programming interfaces without requiring physical hardware swaps. Onboard communication channels maintain deterministic response times and synchronization across multi-axis or turbine drive architectures.
Frequently Asked Questions
Q: What is the primary function of the DS200SDCCG1A board in the control system?
A: It functions as the primary drive controller board, managing core processing, drive regulation, and communication tasks within the Mark V platform.
Q: Can this drive board be hot-swapped while the system is energized?
A: No. All power feeds to the drive cabinet and rack must be completely isolated and locked out before extracting or installing the board.
Q: Does the board support firmware updates via software?
A: Yes. Firmware flash compatibility allows software-based updates of control parameters and operating code through the system interface.
Field Installation Guidelines
Ensure all high-voltage and low-voltage power sources to the drive cabinet are fully isolated and verified dead using a multimeter.
Inspect the slot connectors and backplane pins for alignment, cleanliness, and absence of physical damage prior to installation.
Slide the DS200SDCCG1A board smoothly into the designated guide rails, ensuring secure engagement with the internal connectors.
Fasten any retention mechanisms completely and verify system diagnostic LEDs and configuration parameters via the programming terminal before re-energizing.
