Configured for power connection and multi-input/output management in Mark V turbine control systems, the General Electric DS200PCCAG6A (DS200PCCAG6A) Drive Board provides direct physical/electrical execution.
Suffix Breakdown & Model Matrix
DS200: Designates the product as a Mark V standard footprint component compatible with system backplanes.
PCCA: Identifies the specific core circuit architecture as a Power Connect Card.
G6: Indicates hardware group revision 6.
A: Denotes the primary manufacturing artwork revision level.
Hardware Specifications
Parameter
Specification
Model
DS200PCCAG6A
Brand
General Electric
Origin
USA
Weight
0.32 kg
Dimensions
160 mm x 120 mm x 30 mm
Operating Temp
-20 deg C to +65 deg C
Power Consumption
5 W typical at internal rail voltages
Profinet and Backplane Communication Velocity
Backplane bus communication velocity licenses and deterministic network protocols ensure high-speed data exchange with core processor modules.
I/O density scaling allows seamless integration of multi-input and output signals across Mark V power distribution and control racks.
Firmware flash compatibility supports updates and configuration management via system engineering tools.
Frequently Asked Questions
Q: What is the purpose of the on-board RAM included on the DS200PCCAG6A?
A: The onboard memory chips store local operational parameters, buffering state data required during high-speed power distribution monitoring and multi-I/O processing.
Q: How does this card handle power distribution within the turbine control rack?
A: It manages power connection pathways and routing between system power supplies and internal control bus backplanes while maintaining galvanic separation.
Field Installation Guidelines
Mount the board securely within the designated Mark V cabinet enclosure slot using the integrated fastening hardware.
Ensure all backplane pins and edge connectors are clean and fully seated to prevent intermittent contact faults.
Verify proper system grounding and power rail stability before energizing the control rack.
