- GE WESDAC D20 PS Power Supply Module
Sale
GE WESDAC D20 PS Power Supply Module
No reviews
In stock!
- Part Number: WESDAC D20 PS
- Brand: General Electric
- Type: Power Supply Module
- Dimensions: 4x18.5x12.7cm
- Country of Origin: USA
- Barcode: 8537101190
Share
Additional Specifications
| Color / Pattern |
|
| Power Source |
|
| Communication Protocols |
|
| Controller Design |
|
Product Description
Configured for chassis-tier power regulation and logic loop isolation within WESDAC automation system grids, the GE WESDAC D20 PS (D20 PS Power Supply Module) provides direct physical/electrical execution. It transforms raw field-source direct current distribution into stabilized, filtered internal operating potentials to drive co-located I/O modules, processor logic cores, and integrated LCD status matrices.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | D20 PS |
| Brand | GE (General Electric / Wescom) |
| Origin | United States (US) |
| Weight | Standard WESDAC rack-slot allocation metrics |
| Dimensions | Compact embedded sub-rack layout module housing |
| Operating Temp | -20 to +60 deg C (-4 to +140 deg F) standard engineering envelope |
| Power Input | 24 VDC nominal line voltage input |
| Voltage Tolerance | 24 VDC +/- 10% operational tracking window |
| Integrated Display | Front-panel LCD status, metric tracking, and diagnostic array |
| Communication Layers | Modbus RTU, Modbus TCP/IP, and EtherNet/IP pass-through links |
| Configuration Interface | GE Logic Developer software platform environment |
| Power Conditioning | Embedded power factor correction and harmonic distortion suppression |
| Hardware Protection | Solid-state overvoltage, overcurrent, and short-circuit clamp loops |
GE Industrial Control and Logic Isolation
- Channel-to-Channel Isolation Matrix: The internal DC-to-DC conversion stage contains a high-potential galvanic isolation barrier. This physical boundary isolates the incoming 24 VDC external bus from the sensitive low-voltage logic backplane structure, preventing field-side electrical shorts, transients, and grounding loops from corrupting parallel address registers or processing clocks.
- Loop Integrity Tracking: Integrated diagnostic firmware tracks load profiles, temperature values, and output rail accuracy in real time. State changes, out-of-tolerance voltage variations, and fault parameters are captured, shown on the local LCD interface, and mapped to EtherNet/IP and Modbus diagnostic bits to enable predictive maintenance and minimize system downtime.
