The GE Multilin T35-W00-HCH-F8F-H6H-M6C-P6C-UXX-WXX, also cataloged as the T35 multifunction protective relay module, operates as a dedicated hardware component for multi-winding transformer management, phase differential protection, and circuit metering within utility and industrial power systems.
Hardware Specifications
Parameter
Specification
Model
T35-W00-HCH-F8F-H6H-M6C-P6C-UXX-WXX
Brand
GE (General Electric / Multilin)
Series
Universal Relay (UR) Series / T35
Origin
Canada (CA)
Weight
Approx. 4.1 kg (9.0 lbs) net mass
Dimensions
4U standard 19-inch rack-mount horizontal chassis assembly
Operating Temp
-40 to +70 deg C (-40 to +158 deg F) continuous rating
RS485 interface with Modbus RTU and DNP3 protocol profiles
Dielectric Withstand
2.5 kV RMS for 1 minute duration bounds
Trip Timing Accuracy
+/- 1% or +/- 20 ms mechanical execution tolerance
Measurement Matrix
+/- 0.5% for current monitoring, +/- 0.2% for voltage sensing
GE Industrial Control and System Coordination
Backplane Bus Communication Velocity Licences: The T35 platform utilizes a high-speed parallel backplane bus structure that links the internal digital signal processor (DSP) cards directly with the main calculation processor. It scans AC waveforms, evaluates restraint curves, and completes fault decision algorithms within sub-millisecond loop intervals.
Firmware Flash Compatibility: The module incorporates solid-state non-volatile memory arrays to safeguard user application curves, phase compensation matrices, and sequence-of-event logs. Configuration profiles compiled via EnerVista setup software remain permanently written inside the flash memory chip during complete control power interruptions, eliminating dependency on internal hardware backup batteries.
