GE IS200VPWRH1AHD Analog Measurement Module

Description

The GE IS200VPWRH1AHD Analog Measurement Module is part of the Mark VIe series, engineered for power quality monitoring. It provides advanced measurement of voltage sags, harmonic distortion, and phase imbalance, ensuring reliable operation in critical industrial and energy applications.

Specifications

• Manufacturer: General Electric (GE)

• Model Number: IS200VPWRH1AHD

• Series: Mark VIe

• Function: Power quality monitoring and analog measurement

• Voltage Channels: 3‑phase (or 6 channels with neutral)

• Current Channels: 3 (supports Rogowski coil or CT input)

• Voltage Sag Detection: Response within 0.1 cycle

• Harmonic Analysis: Up to 50th order, ±1% accuracy

• Phase Imbalance Accuracy: ±0.5%

• Input Voltage Range: 85–264 VAC

• Efficiency: >90%

• Operating Temperature: −30 °C to +80 °C

• Protection: Over‑voltage, under‑voltage, over‑current

• Dimensions: 250 × 175 × 60 mm

• Weight: 0.5 kg

• Communication Protocols: Modbus TCP/IP, IEC 61850

Features

• Power Quality Monitoring: Detects voltage sags, harmonics, and imbalance in real time

• High Accuracy: ±1% harmonic measurement, ±0.5% imbalance calculation

• Flexible Inputs: Supports both voltage and current channels with CT/Rogowski coil options

• Fast Response: 0.1 cycle detection for transient events

• Industrial Durability: Wide operating temperature and IP65 protection (optional)

• System Integration: Compatible with SCADA via Modbus TCP/IP and IEC 61850

• Energy Efficiency: >90% efficiency with low ripple and noise
