GE IS200TVBAH2A Vibration Input Terminal Board

Description

The GE IS200TVBAH2A Vibration Input Terminal Board provides passive termination, signal routing, and conditioning paths for vibration probes used with Mark VI/VIe monitoring modules.

Specifications

• Manufacturer: General Electric

• Model: IS200TVBAH2A

• Series: Mark VI / Mark VIe

• Board Type: Vibration Input Terminal Board

• Probe Compatibility: Eddy‑current, seismic, velocity, accelerometer probes

• Channels: Multi‑channel vibration signal termination

• Signal Type: Low‑noise analog vibration and phase signals

• Wiring Method: Screw‑type terminal blocks

• Shielding: Single‑end shield bonding for noise reduction

• Routing: Direct feed to VVIB/VVIM acquisition modules

• Jumpers: Channel configuration jumpers for probe type selection

• Mounting: Panel‑mounted inside Mark VI/VIe cabinets

• Application: Turbine vibration monitoring and rotor‑dynamic analysis

Features

• Multi‑Probe Support: Accepts displacement, velocity, seismic, and accelerometer probes

• Low‑Noise Routing: Preserves analog signal integrity for vibration analysis

• Configurable Channels: Jumpers allow probe‑type selection per channel

• Shield Management: Single‑end bonding reduces induced noise

• Direct VVIB/VVIM Integration: Optimized for GE vibration acquisition modules

• Industrial Durability: Robust PCB and terminals for harsh turbine environments

FAQ

• What_does_IS200TVBAH2A_do: It terminates and routes vibration probe signals to GE VVIB/VVIM modules.

• Which_probes_are_supported: Eddy‑current, seismic, velocity, and accelerometer probes.

• Does_it_have_jumpers: Yes, jumpers configure channels for different probe types.

• How_should_shields_be_wired: Bond shields at one end only to reduce noise.

• Where_is_it_installed: Inside Mark VI/VIe turbine‑control cabinets.
