GE Fanuc IC697MDL740 Discrete Output Module

In stock!
  • Part Number: IC697MDL740
  • Brand: General Electric
  • Type: Relay Output Module
  • Dimensions: USA
  • Country of Origin: USA
  • Barcode: 8537101190

Additional Specifications

Color / Pattern
  • Green
  • Black
Power Source
  • DC-powered
Communication Protocols
  • Ethernet
Controller Design
  • Compact
  • Modular
Tags: PLC , Relay Output Module

Product Description

Overview

The IC697MDL740 is a 16-point discrete relay output module designed for GE Fanuc’s Series 90-70 PLC systems. It supports DC loads from 20 to 60 VDC and delivers fast switching performance with robust current handling, making it ideal for controlling solenoids, motor starters, and pilot lamps.

Key Specifications

Parameter Details
Model Number IC697MDL740
Manufacturer GE Fanuc
Product Series Series 90-70
Module Type Relay Output
Output Channels 16
Voltage Range 20–60 VDC
Rated Current per Channel 2 A
Max Current per Group 4 A
Inrush Current Handling Up to 10× rated current
Response Time 2 ms
Voltage Drop <1 V
LED Indicators Fuse and output status
Configuration PC-based (Windows)
Optional Features Conformal coating, factory options
Safety Features Keying to prevent misinstallation
Dimensions (W×H×D) 4 × 22 × 29.1 cm
Weight 0.66 kg
Product Origin USA
HS Code 8537101190
Condition Brand New
Availability In Stock
Discontinued Status Active
Minimum Order Quantity 1


Features

  • 16 relay outputs with fast 2 ms switching

  • Handles high inrush currents for inductive loads

  • LED indicators for real-time diagnostics

  • Keying mechanism ensures safe module installation

  • Optional conformal coating for harsh environments
