The IC697ALG230 is a high-performance analog input base conversion module designed for GE Fanuc’s Series 90-70 PLC systems. It supports eight differential input channels configurable for voltage or current signals, offering precise analog-to-digital conversion with 16-bit resolution.
Key Specifications
Parameter
Details
Model Number
IC697ALG230
Manufacturer
GE Fanuc
Product Series
Series 90-70
Module Type
Analog Input Base Conversion
Input Channels
8 differential
Input Signal Types
Voltage: ±10 VDC / Current: 4–20 mA
Resolution
16-bit
ADC Type
Integrated 14-bit ADC
Filtering
Individual low-pass filters per channel
Isolation
Opto-isolated from PLC backplane
Wiring Type
Differential
Expansion Support
Up to 7 modules (IC697ALG440/441)
Max Input Channels
120 (with expansion)
Terminal Block
Removable 40-terminal connector
Configuration Software
MS-DOS / Windows-based tools
Dimensions (W×H×D)
4 × 21.7 × 29.1 cm
Weight
0.64 kg
Product Origin
USA
HS Code
8537101190
Condition
Brand New
Availability
In Stock
Discontinued Status
Active
Minimum Order Quantity
1
Features
8 differential analog input channels with 16-bit resolution
Supports ±10 VDC and 4–20 mA signal ranges
Expandable to 120 channels with compatible expander modules
Opto-isolation and low-pass filtering for EMI protection
Removable terminal block for easy wiring and maintenance
Software-based configuration for flexible channel setup
