The GE Fanuc Emerson IC200BEM103 is aDeviceNet network control module within the VersaMax PLC family. It is designed to manage communication across DeviceNet networks, supporting flexible roles as master, slave, or both simultaneously. With support for up to 64 nodes, it enables robust integration of distributed devices in industrial automation systems.
Technical Specifications
Manufacturer: GE Fanuc Emerson
Product Line: VersaMax
Part Number: IC200BEM103
Product Type: DeviceNet Network Control Module
Weight: 0.50 lbs (0.23 kg)
Network Role: Master, Slave, or Master/Slave simultaneously
Network Nodes Supported: 64 nodes
Input Data Capacity: 512 bytes
Output Data Capacity: 512 bytes
Internal Power Consumption: 490 mA
Backplane Voltage: 5 VDC
Baud Rates: 125 Kbps, 250 Kbps, 500 Kbps
Interface Connector: 5-pin open pluggable terminal block
Operating Temperature Range: 0 °C to 60 °C
Relative Humidity: 5–95% (non-condensing)
Key Features
Flexible Network Role: Operates as master, slave, or both simultaneously for versatile network topologies.
High Node Capacity: Supports up to 64 DeviceNet nodes, enabling large-scale distributed control.
Data Throughput: Handles 512 bytes of input and 512 bytes of output data, ensuring efficient communication.
Multiple Baud Rates: Adjustable speeds (125, 250, 500 Kbps) for compatibility with diverse DeviceNet systems.
Compact Design: Lightweight and easy to install with a 5-pin pluggable connector.
Industrial Reliability: Operates in demanding environments with wide humidity tolerance.
Frequently Asked Questions
Q: Can the IC200BEM103 be used in mixed-role networks?
A: Yes, it can act as both master and slave simultaneously, simplifying integration.
Q: What is the maximum data capacity per direction?
A: 512 bytes for input and 512 bytes for output.
Q: Is the module hot-swappable?
A: It should be de-energized before removal or insertion to protect the backplane and network integrity.
