The Honeywell FS-PDB-CPX05, also cataloged as the FS-PDB-CPX05 Power Distribution Board Controller Cabinet, serves as a hardware enclosure for controlled distribution of I/O power across Honeywell automation systems.
Hardware Specifications
Parameter
Specification
Model
FS-PDB-CPX05
Brand
Honeywell
Origin
Not specified
Weight
2 Kg (shipping)
Dimensions
190 × 70 × 46 mm
Operating Temp
Not specified
Power Consumption
Not specified
Product Type
Power Distribution Board Controller Cabinet
Approvals
CE, UL, TUV, CSA
Connectors
4-position action pin header
DIN EN Rails
TS32 / TS35 × 7.5
Used Rail Length
191 mm (7.52 in)
4-20 mA HART Loop Protocol
The FS-PDB-CPX05 integrates with Honeywell distributed control systems, supporting deterministic power routing. Its design ensures compatibility with instrumentation networks utilizing 4-20 mA HART loop protocol, while maintaining isolation across channels to minimize interference and ensure stable cabinet operation.
Frequently Asked Questions (FAQ)
Q: Can the FS-PDB-CPX05 be mounted on both TS32 and TS35 rails? A: Yes, the cabinet supports TS32 and TS35 × 7.5 DIN rails.
Q: What is the function of the connector type? A: The 4-position action pin header provides secure distribution points for module power.
Q: Does the cabinet require certification for installation? A: Yes, it is certified under CE, UL, TUV, and CSA standards for industrial compliance.
Field Installation Guidelines
Mount the FS-PDB-CPX05 securely on TS32 or TS35 rails with full mechanical engagement.
Ensure cabling is routed with separation from high-voltage lines to reduce electromagnetic interference.
Apply shielded wiring with proper grounding to maintain compliance with CE/UL/TUV/CSA standards.
Verify connector seating and locking before energizing the system.
Confirm rail length compatibility during installation to avoid mechanical stress.
