F60 DIO 24/16 01 | HIMA HIMatrix | Digital Input Output Module

Product Overview

The HIMA F60 DIO 24/16 01 functions as a high-density, fail-safe digital input and output module for the HIMatrix platform. It controls 24 digital inputs and 16 digital outputs within a single compact housing.

Technical Specifications

• Module Type: Fail-safe digital input and output module

• Digital Inputs: 24 channels (24 VDC)

• Digital Outputs: 16 channels (24 VDC, 0.5 A or 1 A or 2 A depending on channel grouping and temperature)

• Safety Certification: Up to SIL 3 (IEC 61508) and PL e (EN ISO 13849-1)

• Power Supply: 24 VDC

• Network Interface: safeethernet via RJ45 ports

• Operating Temperature: 0°C to +60°C

Engineering Advantages

• Maximize Cabinet Density: Combining 24 inputs and 16 outputs into one unit eliminates the need for separate I/O racks. It slashes hardware costs and reduces the overall footprint inside heavy-duty marshalling cabinets.

• Isolate Field Disturbances: High-grade internal galvanic isolation shields the processor from field-side voltage spikes and heavy electromagnetic interference (EMI).

• Enable Modular Expansion: The unit operates as a decentralized node via standard Ethernet cables using HIMA safeethernet. You place the module directly near the process equipment to drop your heavy field cabling costs.

• Pinpoint Faults Instantly: The module runs continuous self-tests for short circuits, open lines, and internal processor discrepancies. Individual channel LEDs let technicians identify broken field loops immediately without opening programming software.

FAQs

• Question: Can the F60 DIO 24/16 01 outputs drive inductive loads like heavy solenoid valves?

• Answer: Yes. The outputs contain internal suppression diodes to clamp voltage flyback when switching inductive coils.

• Question: How does the module react if it detects a cross-circuit on the inputs?

• Answer: The module utilizes pulsed test signals to identify short circuits between different wiring runs. It flags the fault to the CPU and forces the corrupted channel to its fail-safe state.

• Question: Do I need separate engineering tools to configure the inputs and outputs?

• Answer: You configure both inputs and outputs simultaneously using a single project database inside HIMA SILworX software.
