The1C31169G02is a high-performance Serial Link Controller (SLC) Personality Module designed for the Emerson Ovation Distributed Control System (DCS).While the electronics module (1C31166G01) handles the processing, this personality module provides the specific physical and electrical interface required for field communication.
Technical Specifications
Module Type: Serial Link Personality Module
Communication Standards:RS-422 / RS-485 (4-Wire)
Transmission Distance: Up to 1,220 meters (4,000 feet)
Isolation: 1000 V AC/DC dielectric isolation (Port to Logic)
Baud Rates: 300 to 19,200 bps (Standard) / Up to 115.2 Kbps (High-speed config)
Ports: 2 Serial Ports (Applications Port for field, Programming Port for diagnostics)
Operating Temperature: -40°C to +85°C (-40°F to +185°F)
Environmental Protection: ISA-S71.04 Class G3 (Conformal coating)
Termination: User-selectable resistor terminations for RS-485 bus stability
Dimensions: 121 mm x 52 mm x 165 mm
Weight: 0.32 Kg (Net) / 1.0 Kg (Shipping)
Common FAQ
What is the difference between the 1C31169G01 and this 1C31169G02?
The G01 variant is designed for RS-232 communication, typically limited to short distances (50 feet).The 1C31169G02 is the RS-422/RS-485 version, designed for robust, long-range industrial networking and multi-drop topologies.
Does this module include the processing electronics?
No.The1C31169G02is aPersonality Module.It must be paired with an Electronics Module (typically the 1C31166G01) and seated in an Ovation I/O Base to function as a complete Link Controller.
